RGBW LIGHTS



RGBW Lights - A2CD0122
LED Focus RGBW Lights, IP68 cable gland, High power, 20⁰ & 30⁰ lens angle, Die-casting powder coated aluminum housing, IP66 outdoor rated. Competitively priced, high-quality products with wide range (30+ designs).
Can be used by lighting designers & architects to create fabulous night time aesthetics, accessibility, security and other special social events for private gardens, public landscapes and LED outdoor lighting.
Some of the highlights are as follows:
Material Specifications: A2CD0122
- Housing & Front Ring:
- 12# Die-casting dark grey powder coated aluminum T=60-80μm.Adhesion of ISO class 1/ASTM class 4B
- Light Window:
- Tempered glass. T=8mm
- LED:
- Prolight RGBW 4 IN1 LED
- Lens:
- Asymmetrical optcal lens,efficiency≥85%
- Glass Pressure Capacity:
- Full area=2578Kgs
- Cable Gland:
- IP68 PG-9 PA66
- Gasket:
- Molding shaped silicone seal
- LED Driver:
- Constant Voltage Input,Constant Current Output
- Operating Temperature:
- -20˚C~40˚C
- Power Cable:
- H05RN-F 5X0.5mm2 L=0.5m
- CCT:
- RGBW
TECHNICAL DATA
Model Number | Light Source | Lens | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
A2CD0122 | 1×6W RGBW 4in1 | A24 | 30⁰ | 24V DC | 24V=338 | 24V=8.1 | 257 | 07 |
