RGBW LIGHTS



RGBW Lights - A3PB0620 B
RGBW Focus Light with powder coated aluminium braket, 4MM tempered glass, all-in-one optical lens, IP66, ambient lighting. Competitively priced, high-quality products with wide range (30+ designs.
Can be used by lighting designers & architects to create fabulous night time aesthetics, accessibility, security and other special social events for private gardens, public landscapes and LED outdoor lighting.
Some of the highlights are as follows:
Material Specifications: A3PB0620 B
- Housing:
- 12# Die-casting dark grey powder coated aluminium T=60-80um. Adhesion of ISO class 1/ASTM class 4B
- Light Window:
- Tempered glass. T=4mm
- LED:
- Prolight RGBW 4in1 LED
- Cable Gland:
- IP68 PG-9 PA66
- Lens:
- All-in-one optical lens, efficiency≥85%
- Bracket:
- Powder coated aluminium.
- Power Cable:
- H05RN-F 5x0.5mm2 L=2.0m
- Gasket:
- Tooling shaped seal
- CCT:
- RGBW
TECHNICAL DATA
Model# | Light Source | Lens | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
A3PB0620 B | 6x4 RGBW 4in1 | A24 | 30⁰ | 24V DC | R=299/G=352/B=350/W=349 | 24V=32 | 1000 | 08 |


IP68 WATERPROOF CONNECTORS
