RGBW LIGHTS

RGBW Lights - A3PB0620 B

RGBW Focus Light with powder coated aluminium braket, 4MM tempered glass, all-in-one optical lens, IP66, ambient lighting. Competitively priced, high-quality products with wide range (30+ designs.
Can be used by lighting designers & architects to create fabulous night time aesthetics, accessibility, security and other special social events for private gardens, public landscapes and LED outdoor lighting.

Compare us with the best outdoor lighting manufacturer before buying the products

A free installation guide is provided with each product

Check out the fascinating designs, quality, and prices

Click the box below to download individual product ecatalog and check out other products of your choice

Some of the highlights are as follows:

Material Specifications: A3PB0620 B

Housing:

12# Die-casting dark grey powder coated aluminium T=60-80um. Adhesion of ISO class 1/ASTM class 4B

Light Window:

Tempered glass. T=4mm

LED:

Prolight RGBW 4in1 LED

Cable Gland:

IP68 PG-9 PA66

Lens:

All-in-one optical lens, efficiency≥85%

Bracket:

Powder coated aluminium.

Power Cable:

H05RN-F 5x0.5mm2 L=2.0m

Gasket:

Tooling shaped seal

CCT:

RGBW

TECHNICAL DATA

Model#	Light Source	Lens	Lens Degree	Input Voltage	Operating Current(MA)	Consumption (W)	Lumance (LM)	IK
A3PB0620 B	6x4 RGBW 4in1	A24	30⁰	24V DC	R=299/G=352/B=350/W=349	24V=32	1000	08

IP68 WATERPROOF CONNECTORS
