RGBW LIGHTS
RGBW Lights - A2BE0320
RGBW Inground light with Stainless steel SUS 316# front ring. Step tempered glass window, asymmetrical lens, IP67 rating for outdoor projects. Competitively priced, high-quality products with wide range (30+ designs)
RGBW Inground light for architectural lighting projects. Used by lighting designers & architects to create fabulous night time aesthetics, accessibility, security, recreation for private gardens, public landscapes and LED outdoor lighting.
Some of the highlights are as follows:
Material Specifications: A2BE0320
- Housing:
- 12# Die-casting dark grey powder coated aluminium T=60-80um. Adhesion of ISO class 1/ASTM class 4B
- Front Ring:
- Hard chromeplated stainless steel SUS 316#
- Light Window:
- Step tempered silver printed glass. T=8mm
- Glass Pressure Capacity:
- Full area = 2274Kg
- LED:
- Prolight RGBW 4in1 LED
- Lens:
- Asymmetrical optical lens, efficiency≥85%
- Gasket:
- Molding shaped silicone seal
- LED Driver:
- Constant Voltage Input, Constant current output
- Operating Temperature:
- -20⁰C-40C⁰
- Power Cable:
- H05RN-F 5x0.75mm2 L=0.5m
- Cable Gland:
- IP68 PG-9 PA66
- Mounting Sleeve:
- ABS 016#
- CCT:
- RGBW
TECHNICAL DATA
Model# | Light Source | Lens | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
A2BE0320 | 3x4W RGBW 4in1 | A24 | 30⁰ | 24V DC | 24V=581 | 24V=13 | 532 | 07 |
