RGB LIGHTS



RGB Lights - B3AB0106


RGB Spot Light with low lumens output. 20 & 30 degree angle, 1x3W RGB 3in1, SMD3535 LED chip, aluminium PCB. Competitively priced, high-quality products with wide range (30+ designs)
Can be used by lighting designers & architects to create fabulous night time aesthetics, accessibility, security and other special social events for private gardens, public landscapes and LED outdoor lighting.

  • Compare us with the best outdoor lighting manufacturer before buying the products
  • A free installation guide is provided with each product
  • Check out the fascinating designs, quality, and prices
  • Click the box below to download individual product ecatalog and check out other products of your choice

  • Some of the highlights are as follows:

    Material Specifications: B3AB0106


    Housing & Front Cover:
    Aluminum anodized finshing or powder painting
    Lens:
    Optical lens,efficiency≥85%
    Light Window:
    Tempered glass.T=3mm
    Cable Gland:
    Nickel coated copper
    Gasket:
    Tooling shaped seal
    LED:
    SMD3535 3 IN 1 LED
    LED Driver:
    Constant Voltage Input,Constant Current Output
    PCB:
    Excellent heat conductivity aluminum,coefficient of heat Conductivity≥2.0w/mk
    LED Driver:
    Constant Voltage Input,Constant Current Output
    Operating Temperature:
    -20˚C~40˚C
    Power Cable:
    H05RN-F 4X0.75mm2 L=2.0m
    CCT:
    RGB

    TECHNICAL DATA

    Model NumberLight SourceLensLens DegreeInput VoltageOperating Current(MA)Consumption (W)Lumance (LM)IK
    B3AB01061x3W RGB 3in1B4930°24V DCR=48 | G=62 | B=6224V=4.19502

    IP68 WATERPROOF CONNECTORS
