RGB LIGHTS
RGB Lights - B4FB1818
RGB Pool Recessed Light with B48 18x2W LED. SUS 316L# body, high lumens output, wall recessed, SMD 3535 LED. Competitively priced, high-quality products with wide range (30+ designs).
These lights come with an ingress protection of IP68. Lighting Designers & Architects use these fixtures to create fabulous nighttime aesthetics, illumination of pool walls, walkways, floor etc.
Some of the highlights are as follows:
Material Specifications: B4FB1818
- Housing:
- Hard chromeplated Molding shaped stainless steel SUS 316L#
- Light Window:
- Step tempered glass. T=10mm
- Cable Gland:
- IP68 PG-11 copper with nickel-coated
- LED:
- SMD 3535 RGB 3 IN 1
- Lens:
- Optical lens,efficiency≥85%
- PCB:
- Excellent heat conductivity aluminum, coefficient of heat conductivity≥2.0w/mk
- Glass pressure capacity:
- Full area=5012Kgs
- LED Driver:
- Constant Voltage Input,Constant Current Output
- Application environment:
- Temperature of water between -20ºC~40ºC less than 1 meter depth.
- Gasket:
- SIlicone gasket
- Power Cable:
- H07RN-F 4X1.0mm2 L=3.0m
- Built-in Overheat Sensor System:
- Automatic Shutdown at 75°C
- Mounting sleeve:
- ABS 075#
- CCT:
- RGB
TECHNICAL DATA
Model Number | Light Source | Lens | Lens Degree | Input Voltge | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
B4FB1818 | 18x2W RGB 3in1 | B48 | 30° | 24V DC | R=630 | G=770 | B=770 | 24V=52 | 1330 | 10 |
