RGB LIGHTS



RGB Lights - B4A0106
RGB Mini Pool Light with chromeplated stainless steel housing. 1x3W low power LED, 103 lumens, IP68 use. Competitively priced, high-quality products with wide range (30+ designs).
These lights come with an ingress protection of IP68. Lighting Designers & Architects use these fixtures to create fabulous nighttime aesthetics, illumination of pool walls, walkways, floor etc.
Some of the highlights are as follows:
Material Specifications B4A0106
- Housing:
- Hard chromeplated molding shaped SUS 316L# stainless steel housing
- Light Window:
- Step tempered glass. T=7mm
- Cable Gland:
- IP68 PG-11 copper with nickel-coated
- LED:
- SMD 3535 RGB 3 IN 1
- Lens:
- Optical lens,efficiency≥85%
- PCB:
- Excellent heat conductivity aluminum, coefficient of heat conductivity≥2.0w/mk
- LED Driver:
- Constant Voltage Input,Constant Current Output
- Application environment:
- Temperature of water between -20ºC~40ºC less than 1 meter depth.
- Gasket:
- SIlicone gasket
- Power Cable:
- H05RN-F 4X0.75mm2 L=3.0m
- Mounting sleeve:
- ABS 061#
- CCT:
- RGB
TECHNICAL DATA
Model Number | Light Source | Lens | Lens Degree | Input Voltge | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
B4A0106 | 1x3W RGB 3in1 | B49 | 30° | 24V DC | R=48 | G=62 | B=62 | 24V=4.1 | 103 | 06 |


IP68 WATERPROOF CONNECTORS
