OUTDOOR WALL LIGHTS



Outdoor Wall Lights - R7BB0227


LED wall lights are recessed and surface mounted lights with different wattages, beam angles and color temperatures. Wattage for outdoor LED wall lights starts from 1W to a maximum of 8W. Beam angles offered are narrow to wide beam. The symmetric and asymmetric beam can be provided for uniform lighting effects.
The body material is aluminium die-cast in powder-coated colors of sanded grey, black, and silver. Adjustable clamps to surface mount the fixtures comes with the fixture. Color temperatures available are 2000K, 3000K and 6000K. Stunning designs, IP65, Symmetrical lens of 15⁰, 24⁰, 38⁰ & 60⁰

  • Compare us with the best outdoor lighting manufacturer before buying the products
  • A free installation guide is provided with each product
  • Check out the fascinating designs, quality, and prices
  • Click the box below to download individual product ecatalog and check out other products of your choice

  • Some of the highlights are as follows:

    Material Specifications: R7BB0227


    Housing:
    12# Die-casting dark grey powder coated aluminium T=60-80um. Adhesion of ISO class 1/ASTM class 4B
    Reflector:
    Optical Reflector, efficiency≥85%
    Light Window:
    PMMA T=6mm
    LED Driver:
    Constant Voltage Input, Constant current output
    LED:
    NICHIA
    Operating Temperature:
    -20⁰C-40C⁰
    Power Cable:
    H05RN-F 2x1.0mm2 L=0.3m (Low Voltage) H05RN-F 3x1.0mm2 L=0.3m (High Voltage)
    CCT:
    3000K/6000K

    TECHNICAL DATA

    Model#Light SourceLensLens DegreeInput VoltageOperating Current(MA)Consumption (W)Lumance (LM)
    R7BB02272x8W COBR824⁰24V DC | 120 | 24024V=822 | 120V=182 | 240V=10324V=19.7 | 120V=21 | 240V=21Cool White = 1018x2 | Warm White = 956x2

    IP68 WATERPROOF CONNECTORS

    Architectural Outdoor Wall Lights Denmark

    Architectural outdoor wall lights for lighting projects in Denmark. Stunning designs, IP65, pre-adjustable lens with various CCT options. LED wall lights are recessed and surface mounted lights with different wattages, beam angles and color temperatures. Wattage for outdoor LED wall lights starts from 1W to a maximum of 8W. Beam angles offered are narrow to wide beam. The symmetric and asymmetric beam can be provided for uniform lighting effects.

    The body material is aluminium die-cast in powder-coated colors of sanded grey, black, and silver. Adjustable clamps to surface mount the fixtures comes with the fixture. Color temperatures available are 3000K and 6000K. Stunning designs, IP65, symmetrical lens of 15⁰, 24⁰, 38⁰ & 60⁰. Premium quality wall lights for landscape lighting projects.
