OUTDOOR WALL LIGHTS
Outdoor Wall Lights - D7AD0237
Competitively priced, high-quality products with wide range (30+ designs)
LED outdoor wall light can be used by Lighting Designers & Architects to create fabulous nighttime aesthetics, accessibility, security, recreation, sport, and other special social events for private gardens, public landscapes and LED outdoor lighting
Some of the high lights are as follows:
Material Specifications D7AD0237
- Housing:
- 12# Die-casting dark grey powder coated aluminium T=60-80um. Adhesion of ISO class 1/ASTM class 4B
- Light Window:
- PC T=6mm
- Gasket:
- Tooling shaped seal
- Driver:
- Main voltage 100V-240V built-in driver
- Operating Temperature:
- -20⁰C-40C⁰
- Power Cable:
- H05RN-F 2x1.0mm2 L=0.3m (Low Voltage) H05RN-F 3x1.0mm2 L=0.3m (High Voltage)
- CCT:
- 2000K/3000K/6000K
TECHNICAL DATA
Model# | Light Source | Input Voltage | Operating Current(MA) | Consumption (W) | IK |
---|---|---|---|---|---|
D7AD0237 | 2x3W NICHIA | 24V DC | 120 | 240 | 24V=268 | 120V=73 | 240V=42 | 24V=6.2 | 120V=8.5 | 240V=8.6 | 06 |
