OUTDOOR WALL LIGHTS



Outdoor Wall Lights - B8CJ0657
Ceiling Down Light with B33D lens & 6x2W LED. Aluminium alloy body, 6 LEDs/fixture, single side light, input voltage options. Competitively priced, high-quality products with wide range (30+ designs). The fixture comes with powder coated colors of dark grey, sanded white & sanded black.
LED outdoor wall light can be used by Lighting Designers & Architects to create fabulous nighttime aesthetics, security, recreation and other social events for private gardens or public landscapes.
Some of the highlights are as follows:
Material Specifications: B8CJ0657
- Housing:
- Extruded aluminium alloy #6063 powder coated aluminium T=60-80um. Adhesion of ISO class 1/ASTM class 4B
- Reflector:
- Optical reflector, efficiency≥85%
- LED:
- NICHIA
- Operating Temperature:
- -20⁰C-40C⁰
- Power Cable:
- H05RN-F 2x1.0mm2 L=0.3m (Low Voltage) H05RN-F 3x1.0mm2 L=0.3m (High Voltage)
- CCT:
- 3000K/6000K
TECHNICAL DATA
Model# | Light Source | Lens | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Luminance(LM) | IK |
---|---|---|---|---|---|---|---|---|
B8CJ0657 | 6x2W | B33D | 30⁰ | 24V DC | 120 | 240 | 24V=562 | 120V=100 | 240V=56 | 24V=13.5 | 120V=12 | 240V=12.2 | Cool White = 830 | Warm White = 681 | 06 |


IP68 WATERPROOF CONNECTORS
