Buried Swimming Pool Lights



Buried Swimming Pool Lights - B4TL0657
Buried swimming pool lights with waterproof housing for linear pool lighting, recessed underwater light and urban project lighting. High powered LED chips are used as light source in these fixtures. Stainless steel housing with 9mm step tempered glass. Standard color temperature and beam angles for swimming pool lights are 2000K, 3000K and 6000K with lens of 8º, 13º, 25º, & 30º. Wattages start 2W upwards to 45W.
Recessed underwater light with RGB/W color changing LED can also create multi-color ambient lighting effects. They use a fraction of the power of traditional incandescent bulbs, and also produce brighter light. Plus, the reduced heat generated by LED pool lights means that they will last longer than incandescent bulbs.
Some of the highlights are as follows:
Material Specifications B4TL0657
- Front cover & Housing:
- Hard Cromeplated molding shaped Stainless Steel SUS 316#
- Light Window:
- Step Tempered glass. T=9mm
- Gasket:
- Silicon Gasket
- Lens:
- Optical Lens, efficiency ≥85%
- LED Driver:
- Constant Voltage Input, Constant Current Output
- PCB:
- Excellent heat conductivity aluminium, coefficientof heat Conductivity ≥2.0w/mk
- Power Cable:
- 24V : H07RN-F 2X1.0mm2 L=3.0m
- Application Environment:
- Temperature of water between -20⁰C~40⁰C less than 1 Mtr Depth
- CCT:
- 2000K/3000K/6000K
- Dimmable Support:
- Triac PWM 1-10V Dali
TECHNICAL DATA
Model# | Light Source | LENS | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
B4TL0657 | 6x2W | B27 | 30⁰ | 24V DC | 24V=500 | 24V=12 | Cool White=808 | Warm White=688 | 08 |


IP68 WATERPROOF CONNECTORS




Buried swimming pool lights
Buried swimming pool lights with waterproof housing for linear pool lighting, recessed underwater light and urban project lighting. These waterproof lights can also be used in fountains to give underwater lighting effects. These lights make the pool more attractive and help in highlighting the shape and texture of the pool. Swimming pool light illuminates the pool area and also covers dark areas.
CCT of 2000k/3000k & 6000k with Triac, PWM ,1-10V & Dali dimming options. Lighting designers & architects use these fixtures to create fabulous nighttime aesthetics, Illumination of pool walls, floor etc. Multiple lights can be placed in depending on how big the pool is. The temperature of water between -20⁰C~40⁰C less than 1 Mtr Depth is applicable for this light.
