Lighting For Ponds



Lighting For Ponds - A4AA0357
Lighting for ponds in resorts & water parks. Application include lights around pool, color changing LED poolights and waterfall lighting. The entire swimming pool lights are made of SS316 material to make it rust or corrosion free. Stainless steel housing with 4mm step tempered glass. Standard color temperature and beam angles for swimming pool lights are 2000K, 3000K and 6000K with lens 15º & 30º. Wattages start 2W upwards to 45W.
These lights come with an ingress protection of IP68. Multiple lights can be placed in depending on how big the pool is. Swimming pool lights can also be provided with RGB/W color changing LEDs with DMX control systems. These color changing LED poollights can also provide greater safety for folks in and out of the swimming pool.They are also important as they can add a visual impact to the pool landscape.
Some of the highlights are as follows:
Material Specifications A4AA0357
- Front cover & Housing:
- Hard Chromeplated Molding Shaped SUS 316L# Stainless Steel Housing
- Light Window:
- Step Tempered glass. T=8mm
- Gasket:
- EPDM Gasket
- Lens:
- All-in-one optical Lens, efficiency ≥85%
- LED Driver:
- Constant Voltage Input, Constant Current Output
- PCB:
- Excellent heat conductivity aluminium, coefficientof heat Conductivity ≥2.0w/mk
- Power Cable:
- 24V : H07RN-F 2X1.0mm2 L=3.0m
- Application Environment:
- Temperature of water between -20⁰C~40⁰C less than 1 Mtr Depth
- CCT:
- 2000K/3000K/6000K
- Dimmable Support:
- Triac PWM 1-10V Dali
TECHNICAL DATA
Model# | Light Source | LENS | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
A4AA0357 | 3x2W | A18 | 30⁰ | 24V DC | 24V=245 | 24V=5.9 | Cool White=466 | Warm White=383 | 07 |


IP68 WATERPROOF CONNECTORS




Lighting for ponds
Lighting for ponds in resorts & water parks. Applications include lights around pool, color changing LED poollights and waterfall lighting. These lights come with a variety of beam angles with stainless steel housing and 7mm step tempered glass. These Swimming Pool lights come with an ingress protection of IP68. One of the applications can also be waterfall lighting.
CCT of 2000k/3000k & 6000k with Triac, PWM ,1-10V & Dali dimming options. Lighting Designers & Architects use these fixtures for resorts & water parks to create fabulous nighttime aesthetics and illumination of pool walls. Swimming pool light illuminates the pool area and also covers dark areas. Multiple lights can be placed in depending on how big the pool is. The temperature of water between -20⁰C~40⁰C less than 1 Mtr depth is applicable for this light.
