Underwater LED Poollights
Underwater LED Poollights - B4A0158
Underwater LED poollights for hotel lighting, luxury pools, inground pond lights and swimming pool lighting with low wattage output. Stainless steel housing with 7mm step tempered glass. These lights make the pool more attractive and help in highlighting the shape and texture of the pool. Standard color temperature and beam angles for swimming pool lights are 2000K, 3000K and 6000K with lens 9º, 15º, 20º, 30º & 45º. Wattages start 2W upwards to 45W.
Swimming pool light illuminates the pool area and also covers dark areas. These lights come with an ingress protection of IP68 and are available with Triac, PWM, 1-10V & Dali dimming options. Swimming pool lights can also be provided with RGB/W color changing LEDs with DMX control systems. Lighting designers & architects use these fixtures to create fabulous nighttime aesthetics, illumination of pool walls, walkways, floor etc.
Some of the highlights are as follows:
Material Specifications B4A0158
- Front cover & Housing:
- Hard Chromeplated Molding Shaped Stainless Steel SUS 316#
- Light Window:
- Step Tempered glass. T=7mm
- Gasket:
- Silicon Gasket
- Lens:
- Optical lens, efficiency ≥85%
- LED Driver:
- Constant Voltage Input, Constant Current Output
- PCB:
- Excellent heat conductivity aluminium, coefficientof heat Conductivity ≥2.0w/mk
- Power Cable:
- 24V : H07RN-F 2X1.0mm2 L=3.0m
- Application Environment:
- Temperature of water between -20⁰C~40⁰C less than 1 Mtr Depth
- CCT:
- 2000K/3000K/6000K
- Dimmable Support:
- Triac PWM 1-10V Dali
TECHNICAL DATA
| Model# | Light Source | LENS | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
|---|---|---|---|---|---|---|---|---|
| B4A0158 | 1x3W | B33D | 30⁰ | 24V DC | 24V=110 | 24V=2.6 | Cool White=174 | Warm White=139 | 06 |
IP68 WATERPROOF CONNECTORS
Underwater LED poollights
Underwater LED poollights for hotel lighting, luxury pools, inground pond lights and swimming pool lighting with low wattage output. Swimming pool light with hard chrome-plated stainless steel housing and 7mm step tempered glass. The lens can be adjusted to 9,15,20,30 & 45 degrees depending on the lighting effect. These lights come with an ingress protection of IP68. CCT of 2000k/3000k & 6000k with Triac, PWM ,1-10V & Dali dimming options.
Recessed mini pool lights is one of the majorly used types of Outdoor lighting fixtures used by Lighting Designers & Architects to create fabulous nighttime aesthetics, accessibility, security and other special social events for private gardens, public landscapes, Illumination of pool walls, floor and LED outdoor lighting.
Lighting designers & architects also use these fixtures to create fabulous nighttime aesthetics for hotel lighting. These lights make the pool more attractive and help in highlighting the shape and texture of the pool. Swimming pool light illuminates the pool area and also covers dark areas. The IP68 connectors help install the lights easily.
