DRIVE OVER LIGHTS



Drive Over Lights - 2E2CA0157 A


LED drive-over lights with die-cast aluminium body. IK10 rated, double side light, 1x2W, SUS316 front cover, 20+ designs. Material of these fixtures are robust and are made of die-cast aluminium body with powder coated colors. Front cover of the light is of high-grade stainless steel 316 to make it rust or corrosion free. These lights come with an ingress protection of IP67.
Offer Triac, PWM, 1-10V & Dali dimming options. Standard color temperature for drive over lights are 2000K, 3000K and 6000K. Wattages are low starting at 0.8W with maximum 4W.

  • Compare us with the best manufacture before you buy our LED outdoor Lighting products
  • A free installation guide is provided with each product
  • Check out the fascinating designs, quality, and prices
  • Click each of the boxes below and download individual products of your choice

  • Some of the highlights are as follows:

    Material Specifications: 2E2CA0157 A


    Housing:
    12# Die-casting dark grey powder coated aluminum. T=60-80μm.Adhesion of ISO class 1/ASTM class 4B
    Front Cover:
    Hard chromeplated stainless steel SUS 316#
    Load Capacity:
    >2000kg
    Gasket:
    Molding shaped silicone seal
    Operating Temperature:
    -20˚C~40˚C
    Power Cable:
    H05RN-F 2X1.0mm2 L=0.5m(low voltage) H05RN-F 3X1.0mm2 L=0.5m(high voltage)
    Mounting Sleeve:
    ABS 065#
    Dimmable Support:
    Triac PWM 1-10V Dali
    CCT:
    2000K/3000K/6000K

    TECHNICAL DATA

    Model NumberLight SourceInput VoltgeOperating Current(MA)Consumption (W)Luminance(LM)IK
    2E2CA0157 A1x2W24V DC | 120 | 24024V=108 | 120V=47 | 240V=2824V=2.5 | 120V=3 | 240V=3Cool White = 4.8 | Warm White = 4.310

    IP68 WATERPROOF CONNECTORS

    LED drive-over lights with die-cast aluminium body. IK10 rated, double side light, 1x2W, SUS316 front cover, 20+ designs. Material of these fixtures are robust and are made of die-cast aluminium body with powder coated colors. Front cover of the light is of high-grade stainless steel 316 to make it rust or corrosion free. These lights come with an ingress protection of IP67. Offer Triac, PWM, 1-10V & Dali dimming options. Standard color temperature for drive over lights are 2000K, 3000K and 6000K. Wattages are low starting at 0.8W with maximum 4W.

    Check out our range of outdoor lights for architectural lighting solutions: https://www.est.net.in/outdoor-led-lighting/
