LED RECESSED WOODEN FLOOR LIGHT



LED Recessed Wooden Up-Light - FC2XCR0657 | FC2XCS0657

Asymmetrical wooden floor lights with FC04 45⁰x35⁰ lens & OSRAM LED chip. 24/120/240V voltage options, dark grey housing & RoHS compliant. These lights come with ingress protection of IP67 and powder coated alumimium housing.
LED recessed Wooden Floor lights can be used for deck lighting, wooden floor lighting, nighttime aesthetics, security etc. These lights makes the outdoor living space look more attractive & also improves visibility. It can also be used for step lighting, highlight a landscape feature or a pool.

  • Compare us with the best manufacturer before buying our LED outdoor Lighting products
  • A free installation guide is provided with each product
  • Check out the fascinating designs, quality, and prices
  • Click the box below to download individual product ecatalog and check out other products of your choice

  • Some of the highlights are as follows:

    Material Specifications: FC2XCR0657 | FC2XCS0657


    Front cover & Housing:
    12# Die-casting dark grey powder coated alumimium T=60-80μm. Adhesion of ISO class 1/ASTM class 4B, Hard Crome plated stainless Steel SUS 316#
    Light Window:
    Tempered Frosted Step glass. T=8mm
    LED:
    OSRAM
    Glass Pressure Capacity:
    Full Area = 3370Kg
    Power Cable:
    H05RN-F 2X1.0mm2 L=0.5m H05RN-F 3X1.0mm2 L=0.5m
    Operating Temperature :
    -20⁰C~40⁰C
    CCT:
    2000K/3000K/6000K
    Dimmable Support:
    Triac PWM 1-10V Dali

    TECHNICAL DATA

    Model#Light Source LensLens DegreeInput VoltageOperating Current(MA)Consumption (W)Lumance (LM)IK
    FC2XCR06576x2WFC0445⁰x35⁰24V DC | 120/24024V=541 | 120=111 | 240=6424V=13 | 120V=13.5 | 240V=13.7Cool White=753 | Warm White=61308
    FC2XCS06576x2WFC0445⁰x35⁰24V DC | 120/24024V=541 | 120=111 | 240=6424V=13 | 120V=13.5 | 240V=13.7Cool White=757 | Warm White=61308

    IP68 WATERPROOF CONNECTORS
