LED FOCUS LIGHT
LED Focus Light - B3XBM0127
The very best product at competitive price high-quality with widest ranges (50+ designs) & extensive product depth: material, finish colors, beam angles, light source & accessories, the newest include the RGBW range of Outdoor Focus Light fixtures with DMX controls
Outdoor LED Focus light is one of the majorly used types of Outdoor lighting fixtures used by Lighting Designers & Architects to create fabulous nighttime aesthetics, accessibility, security, recreation, sport, and other special social events for private gardens, public landscapes and LED outdoor lighting
Some of the high lights are as follows:
Material Specifications B3XBM0127
- Front cover & Housing:
- 12# Die-casting dark grey powder coated aluminium
- Lens Window:
- Tempered glass. T=4mm
- LED Driver:
- ConstantVolatage Input, Constant Current Output
- Lens:
- Optical lens, efficiency ≥85%
- LED:
- OSRAM
- Operating Temperature:
- -20⁰C ~ 40⁰C
- Power Cable:
- H05RN-F 2X1.0mm2 L=2.0m(low voltage) H05RN-F 3X1.0mm2 L=2.0m(high voltage)
- CCT:
- 2000K/3000K/6000K
- Dimmable Support:
- Triac PWM 1-10V Dali
TECHNICAL DATA
Model# | Light Source | LENS | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
B3XBM0127 | 1x8W COB | B14 | 30⁰ | 24V DC | 120 | 240 | 24V=411 | 120V=88 | 240V=50 | 24V=9.8 | 120V=10.8 | 240V=10.8 | Cool White=761 | Warm White=696 | 07 |
