LED Outdoor Ground Lights
LED Outdoor Ground Lights R2GFR0173 | R2GFS0173
Dedicated manufacturers of LED Focus lights & Spotlights for architectural outdoor lighting, garden & landscape.
LED outdoor ground lights for buried gazebo lighting ideas, recessed terrace lighting, walkway lights for bridges and residential lighting. 1x25W COB, 5000kgs glass capacity, hard chrome-plated steel, low/high voltage. Stainless steel housing and 10mm step tempered glass. Symmetrical beam options of 12, 25, & 38 degree can be provided depending on the lighting effect. These lights come with an ingress protection of IP66 with low/high voltage fixture.
LED outdoor ground lights are perfect for creating a fabulous night-time aesthetic. Plus, they're also great for pathfinding purposes. Inground LED lights are a popular type of outdoor lighting fixture used to highlight pathways, driveways & create fabulous night time aesthetics for parks & hotels. These fixtures come with IK10 rating and have 5000kgs glass capacity with 1x25W COB LED & hard chrome-plated steel front ring. We give emphasis on high quality as our lighting fixtures are made of die-cast aluminium with stainless steel front ring which makes the fixture non-corrosive, durable and stylish.
Some of the highlights are as follows:
Material Specifications R2GFR0173 | R2GFS0173
- Front cover & Housing:
- #12 Die-casting dark grey powder coated aluminium, T=60-80μm, Hard chromeplated Stainless Steel SUS 316L#
- Light Window:
- Tempered frosted step glass. T=10mm
- Reflector:
- Opal Reflector efficiency ≥90%
- LED:
- NICHIA COB
- LED Driver:
- Constant Voltage Input, Constant Current Output
- Gasket:
- Molding Shaped Seal
- Power Cable:
- H05RN-F 2X1.0mm2 L=0.5m(Low voltage) H05RN-F 3X1.0mm2 L=0.5m(High voltage)
- Operating Temperature:
- -20⁰C~40⁰C
- CCT:
- 3000K/6000K
TECHNICAL DATA
| Model# | Light Source | LENS | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
|---|---|---|---|---|---|---|---|---|
| R2GFR0173 | 1x25W COB | R16 | 12⁰ | 24V DC | 120V | 240V | 24V=1040 | 120V=240 | 240V=130 | 24V=25 | 120V=28 | 240V=28 | Cool White = 2365 | Warm White = 1849 | 10 |
| R2GFS0173 | 1x25W COB | R16 | 12⁰ | 24V DC | 120V | 240V | 24V=1040 | 120V=240 | 240V=130 | 24V=25 | 120V=28 | 240V=28 | Cool White = 2365 | Warm White = 1849 | 10 |
IP68 WATERPROOF CONNECTORS
LED outdoor ground lights
LED outdoor ground lights for buried gazebo lighting ideas, recessed terrace lighting, walkway lights for bridges and residential lighting. Stainless steel housing and 10mm step tempered glass. Symmetrical beam options of 12, 25, & 38 degree can be provided depending on the lighting effect. These lights come with an ingress protection of IP66 with a low/high voltage fixture.
Inground LED lights are a popular type of outdoor lighting fixture used to highlight pathways, driveways & create fabulous night time aesthetics for parks & hotels. These fixtures come with IK10 rating and have 5000kgs glass capacity with 1x25W COB LED & hard chrome-plated steel front ring.
LED outdoor ground lights for Urban landscape, garden lighting & patios with 12°~60° beam options & frosted diffusers. These lights create luminous paths and enhance architecture or tree clusters. They’re also perfect for highlighting walls and columns. Tough glass and aluminium body allows the fixture to withstand extreme weather and vandalism. So if you’re looking for a durable and stylish way to light up your outdoors, COB LED outdoor inground lights are the way to go.
When it comes to outdoor lighting, there are many different options to choose from. One option that has been gaining popularity in recent years is COB inground lighting. COB inground lights are a type of outdoor light that is installed in the ground, and uses a single LED chip-on-board. They are perfect for buried gazebo lighting ideas, recessed terrace lighting and residential lighting. One of the applications can also be as walkway lights for bridges.
LED outdoor ground lights are perfect for creating a fabulous night-time aesthetic. Plus, they’re also great for pathfinding purposes. When it comes to installation, COB LED outdoor inground lights are very easy to install. When it comes to inground outdoor lighting, there are a lot of options available. These lights are available in 12°~60° beam options with frosted diffusers for soft/anti-glare lighting effects. If you’re looking for a way to add some extra flair to your outdoor space, COB LED outdoor inground lights are a great option.
There are many benefits of using these outdoor lights. For one, they are very energy efficient. Plus, they emit much brighter light, so you’ll be able to see better at night. These fixtures can light up walkways, garden pathways or patios which also provide security. We give emphasis on high quality as our lighting fixtures are made of die-cast aluminium with stainless steel front ring which makes the fixture non-corrosive, durable and stylish.
Similar buried lights for commercial projects.
