INGROUND COB LIGHTS
Inground COB Lights R2EFR0129 | R2EFS0129
IP66 COB floor lamp for commercial projects in Mauritius. 22⁰ symmetrical beam, high load bearing capacity, 12W COB & 8mm frosted glass. Hard chrome-plated stainless steel housing and 8mm step tempered glass. The lens options are 15, 24, 38 & 60 degree depending on the lighting effect. These lights come with an ingress protection of IP66.
CCT of 2000K/3000K & 6000K available. IP66 COB floor lamp is useful to light pathways, walkways, garages and for commercial projects in Mauritius. Available in 22⁰ symmetrical beam with high load bearing capacity & high quality 12W COB for uniform lighting. The installation of these floor recessed lights can be used as guide lights for public areas and gardens.
Some of the highlights are as follows:
Material Specifications R2EFR0129 & R2EFS0129
- Front cover & Housing:
- #12 Die-casting dark grey powder coated aluminium, T=60-80μm, Hard chromeplated Stainless Steel SUS 316L#
- Light Window:
- Tempered frosted step glass. T=8mm
- Reflector:
- Opal Reflector efficiency ≥90%
- LED:
- NICHIA COB
- LED Driver:
- Constant Voltage Input, Constant Current Output
- Gasket:
- Molding Shaped Seal
- Power Cable:
- H05RN-F 2X1.0mm2 L=0.5m(Low voltage) H05RN-F 3X1.0mm2 L=0.5m(High voltage)
- Operating Temperature:
- -20⁰C~40⁰C
- CCT:
- 3000K/6000K
TECHNICAL DATA
Model# | Light Source | LENS | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
R2EFR0129 | 1x12W COB | R18 | 22⁰ | 24V DC | 120V | 240V | 24V=529 | 120V=102 | 240V=64 | 24V=12.7 | 120V=14 | 240V=14 | Cool White = 1357 | Warm White = 1230 | 10 |
R2EFS0129 | 1x12W COB | R18 | 22⁰ | 24V DC | 120V | 240V | 24V=529 | 120V=102 | 240V=64 | 24V=12.7 | 120V=14 | 240V=14 | Cool White = 1357 | Warm White = 1230 | 10 |
IP68 WATERPROOF CONNECTORS
IP66 COB floor lamp for commercial projects in Mauritius. 22⁰ symmetrical beam, high load bearing capacity, 12W COB & 8mm frosted glass. Hard chrome-plated stainless steel housing and 8mm step tempered glass. The lens options are 15, 24, 38 & 60 degree depending on the lighting effect. These lights come with an ingress protection of IP66.
CCT of 2000K/3000K & 6000K available. IP66 COB floor lamp is useful to light pathways, walkways, garages and for commercial projects in Mauritius. Available in 22⁰ symmetrical beam with high load bearing capacity & high quality 12W COB for uniform lighting. The installation of these floor recessed lights can be used as guide lights for public areas and gardens.
