OUTDOOR LIGHT LED INGROUND LIGHT




LED Inground Light C2WDR0157 A


LED inground light for outdoor lighting applications. These LED profiles come in various wattage & ingress protection of IP66 - IP67. Transparent and Frosted covers / diffusers with buried mounting sleeves and accessories help to form uniform lighting. Front cover of the light is made of high-grade stainless steel 316 and aluminium AL6063-T5. Different beam angles for LED inground lights can be combined with LEDs to create infinite architectural and interior lighting solutions. With the advancement of LED technologies, lighting designers, architects & interior designers can use these versatile LED outdoor lights in their projects to create infinite lighting solutions for indoor & outdoor lighting. These inground LED lighting fixtures will create a beautiful ambiance and enhance the environment. The fixtures are versatile which can add a visual impact and also plays a critical role in safety apart from lighting.  The application of this light fixture can be to high light walls, columns, façades. Some of the features are as follows:

Material Specifications C2WDR0157 A


Front cover & Housing:
CRI > Aluminum anodized finshing or powder painting
Lens:
Optical lens,efficiency≥85%
Light Window:
Tempered glass.T=3mm
LED:
OSRAM
PCB:
Excellent heat conductivity aluminum,coefficient of heat Conductivity≥2.0w/mk
LED Driver:
Constant Voltage Input,Constant Current Output
Operating temperature:
-20˚C~40˚C
Power Cable:
H05RN-F 2X1.0mm2 L=2.0m(low voltage) H05RN-F 3X1.0mm2 L=2.0m(high voltage)
CCT:
2000K/3000K/6000K
TECHNICAL DATA
Model#Light Source LENSLens DegreeInput VoltageOperating Current(MA)Consumption (W)Lumance (LM)IK
EST-C2WDR0157 A1x2WC945°/35°24V DC | 120-240V AC24V = 105MA | 240V = 28MA24V = 2.5 | 240V = 3.1Cool White=158 | Warm White=13008

IP68 WATERPROOF CONNECTORS

LED Mini Inground light with symmetric/ asymmetric lens with single and RGB color inground LED outdoor lights for IP66 & IP67 application. Front cover of the light is made of high-grade stainless steel 316 and aluminium AL6063-T5. Transparent and Frosted covers / diffusers with buried mounting sleeves and accessories help to form uniform lighting. These inground LED lighting fixtures will create a beautiful ambiance and enhance the environment. The fixtures are versatile which can add a visual impact and also plays a critical role in safety apart from lighting.  The application of this light fixture can be to high light walls, columns, façades. These outdoor lights are available in single and RGB color with symmetric/ asymmetric lens for IP66 & IP67 applications.

Similar product: https://www.est.net.in/outdoor-led-lighting/outdoor-lights-led-inground-lights/led-inground-light-b2wdr0157-b2wds0157/
