OUTDOOR LIGHTS - WALL WASHER



Wall Washer - B2RLB1257 | B2RLB2457


Premium quality Wall washer inground lights at competitive price, with a range of optics and sizes to select. New range of wall washer has color option of RGBW with DMX controls. High quality wall washer with chrome plated stainless steel housing, 6mm tempered frosted step glass. The lens angle is 120 degree and the light comes with Ingress protection of IP67. CCT options are 2000K | 3000K | 6000k with Triac, PWM, 1-10V & Dali dimming possible.
Lighting designers & architects use these wall washers to create fabulous night time aesthetics, Illuminate walls, columns, façades, many other outdoor lighting applications. One can create wonders with the right distribution of light. Applications for wall washer can be in resorts, hotel lighting, park lighting, façade lighting, etc.

  • Compare us with the best manufacture before you buy our LED outdoor Lighting
  • A free installation guide is provided with each product
  • Check out the fascinating designs, quality, and prices
  • Click each of the boxes below and download individual products of your choice

  • Some of the highlights are as follows:

    Material Specifications: B2RLB1257 | B2RLB2457


    Front cover & Housing:
    Extruded Aluminium, powder coated. Hard Chrome-plated stainless steel SUS316L
    Light Window:
    Tempered Frosted Step glass. T=6mm
    Lens:
    Optical lens, efficiency≥85%
    LED:
    OSRAM
    Gasket:
    Glass and housing are silicon sealed
    Power Cable:
    H05RN-F 2X1.0mm2 L=0.5m H05RN-F 3X1.0mm2 L=0.5m
    Operating Temperature :
    -20⁰C~40⁰C
    CCT:
    2000K/3000K/6000K
    Dimmable Support:
    Triac PWM 1-10V Dali

    TECHNICAL DATA

    Model#Light SourceLensLengthLens DegreeInput VoltageOperating Current(MA)Consumption (W)Lumance (LM)IK
    B2RLB125712x1.5WB3254920⁰24V DC | 120/24024V=910 | 120=143 | 240=7924V=22 | 120V=17 | 240V=17.5Cool White=1108 | Warm White=102007
    B2RLB245724x1.5WB32102520⁰24V DC | 120/24024V=1826 | 120V=312 | 240V=15624V=44 | 120V=36 | 240V=36.4Cool White=2957 | Warm White=205507

    IP68 WATERPROOF CONNECTORS

    Exterior wall washer lights, Lighting designers & architects use these wall washers to create fabulous night time aesthetics, Illuminate walls, columns, façades, many other outdoor lighting applications. One can create wonders with the right distribution of light. Applications for wall washer can be in resorts, hotel lighting, park lighting, façade lighting, etc.

    Outdoor linear wall washers for lighting facades of skyscrapers, historic monuments, government building, railway station, airports and other city skylines with RGB/RGBW/mono color. Wall washing illuminates a vertical surface with uniform brightness and draws attention to the outdoor wall, and can be used to accentuate an entrance, fireplace, or artwork.

    There are a few things to keep in mind if you’re considering using outdoor wall washers. First, you’ll need to decide what type of fixture you want. There are two main types of wall washers: linear and grazing. Linear wall washers are designed to evenly illuminate a large area, while grazing fixtures create more of a “spotlight” effect. Wall washers evenly light up large areas and enhance the architecture.

    The most popular reason to use an outdoor Exterior wall washer lights is to illuminate an architectural facade – typically lighting facades of skyscrapers & city skylines. These fixtures are available in RGB/RGBW/mono color and are often used to light up historic monument, government building and railway station.

    If you’re looking for a way to add some extra light and interest to your home’s exterior, consider outdoor wall washers. These fixtures are designed to evenly illuminate large vertical surfaces, adding a touch of drama and helping to highlight the architecture of your home.

    IP65, IP66, IP67 & IP68 outdoor rated, mono or multi-color LED for lighting projects. Wattages start from 6W to a maximum of 120W. Standard beam angles offered are narrow to wide beams from 9, 12, 15, 20, 24, 40, 60. wall wash asymmetric beam angle of 10*30 and 15*32 can be provided as well.

    Spacing between the wall washer and the surface helps to determine the level of brightness. For a focused, bright effect the fixture should be placed closer to the wall. Wall washers with high wattages can light up buildings upto 50 floors high. The purpose of wall washers is to illuminate vertical surfaces and enhance the architecture.

    It also helps in highlighting the details and textures on a structure or wall and gives a modern look to the lighting space. Wall washers are also available with in-built drivers & built-in DMX decoders for easy installation and DMX controls.

    Body material used is aluminium die-cast in powder coated colors of sanded grey, black and silver. Adjustable clamps and accessories are SS316 to protect the fixture from corrosion. These lights are also available in RGB and RGBW, and can be provided along with DMX controls to create infinite lighting effects. Lighting designers and architects can use these high quality LED fixtures in their lighting designs, landscape & prestigious projects.
