UNDERWATER LIGHTS



Underwater Lights - R5ZA0171
Underwater lights surface mounted for waterbody applications, to highlight a structure inside water. The fixtures are of high grade stainless steel 316 material, suitable for places near salt-water. NICHIA and CREE LED source is used in underwater lights. The lifespan for the fixtures is above 50,000Hrs. With 24VDC the lumen output is high. A narrow and wide beam optics are standard options to chose. Normal color temperatures for underwater lights is 2000K, 3000K and 6000K. RGB and RGBW is also possible with DMX control system.
Some of the highlights of the products are as follows:
Material Specifications: R5ZA0171
- Front cover & Housing:
- Hard Cromeplated Molding Shaped Stainless Steel SUS 316L#
- Light Window:
- PMMA 8mm
- Gasket:
- Silicon Gasket
- LED:
- NICHIA
- Reflector:
- Optical Reflector, efficiency ≥85%
- LED Driver:
- Constant Voltage Input, Constant Current Output
- PCB:
- Excellent heat conductivity aluminium, coefficientof heat Conductivity ≥2.0w/mk
- Power Cable:
- 24V : H07RN-F 2X1.0mm2 L=3.0m
- Application Environment:
- Temperature of water between -20⁰C~40⁰C less than 1 Mtr Depth
- CCT:
- 3000K/6000K
TECHNICAL DATA
Model# | Light Source | LENS | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
R5ZA0171 | 1x20W | R19 | 22⁰ | 24V DC | 24V=860 | 24V=20.5 | Cool White=1679 | Warm White=1478 | 08 |


IP68 WATERPROOF CONNECTORS




Adjustable Underwater Flood Light – Underwater Flood Light with R19 symmetrical lens and adjustable beam angle. SUS 316L#, RoHS compliant, optical reflector, PMMA light window. The fixtures are of high grade stainless steel 316 material, suitable for places near salt-water. NICHIA and CREE LED source is used in underwater lights. The lifespan for the fixtures is above 50,000Hrs.
Check out our range of outdoor swimming pool lights: Swimming Pool Lights
Underwater lights for pools, swimming pool lights and fountain light with RGB/W color changing LED for multi-color ambient light. LED poollights are a great way to bring your water to life with delightful colors and enchanting light shows. These led underwater pool light fixtures consume less energy than halogen or incandescent lights, making them more environmentally friendly. Led inground pool light also lets you swim at night with multicolored ambient light. LED pool lights allow you to change colors with a flip of a switch, giving you even more control over your swimming experience.
If you’re looking for Adjustable Underwater Flood Light swimming pool lights that are both energy-efficient and long-lasting, then led poollights are a great option. LED pool lights use a fraction of the power of traditional incandescent bulbs, and they also produce brighter light. Plus, the reduced heat generated by LED pool lights means that they will last longer than incandescent bulbs. So if you’re looking for an environmentally-friendly and cost-effective underwater lighting solution for your swimming pool, fountain lights, lighting for waterfall then LED pool lights are definitely worth considering.
Adjustable Underwater Flood Light Swimming pool lights are a complete necessity when it comes to any pool installation. From safety, to practicality, to pure enjoyment, they are sure to make any backyard swim a memorable and long-lasting experience. All the lights for pools are made of premium components and we carry only the highest quality products so that you can rest assured your investment will last. With our wide selection of swimming pool lights, you’re sure to find the perfect fit for your needs.
