OUTDOOR LED BOLLARD LIGHT



LED Bollard Light - D9ADL4234 | D9ADM4234 | D9ADH4234

Outdoor Bollard Lights with PMMA diffuser & SMD3030 LED. IP65 rating, die-cast aluminium body, BIS certification, 3000K & 6000K CCT. Available in powder coated colors of sanded black, light sanded grey and dark grey. Triac, PWM, 1-10V & Dali dimming available.
Bollard lights are a type of architectural outdoor lighting fixture which gives off light from the top or the sides. It is used to illuminate steps, walkways or pathways. Available in various heights and designs. The uses of this light can be in playgrounds, roadways, malls, parks, parking spots and safety. Bollards are also applicable for security purpose and helps in managing traffic.

  • Compare us with the best manufacturer before you buy our LED outdoor Lighting products
  • A free installation guide is provided with each product
  • Check out the fascinating designs, quality, and prices
  • Click the box below to download individual product ecatalog and check out other products of your choice

  • Some of the highlights are as follows:

    Material Specifications: D9ADL4234 | D9ADM4234 | D9ADH4234


    Front cover & Housing:
    12# Die-casting powder coated alumimium T=60-80μm. Adhesion of ISO class 1/ASTM class 4B, Hard Crome plated stainless Steel SUS 316#
    Light Window:
    PMMA
    LED:
    SMD3030
    LED Driver:
    Constant Voltage Input, Constant Current Output
    Power Cable:
    H05RN-F 3X1.0mm2 L=0.3m H05RN-F 3X1.0mm2 L=0.5m H05RN-F 3X1.0mm2 L=1.0m
    Operating Temperature :
    -20⁰C~40⁰C
    CCT:
    3000K/6000K
    Base:
    Standard Base / Flange Base
    Dimmable Support:
    Triac PWM 1-10V Dali

    TECHNICAL DATA

    Model#Light Source Input VoltageOperating Current(MA)Consumption (W)Lumance (LM)
    D9ADL423442x0.2W120/240V120=76 | 240=41120V=8.6 | 240V=9Warm White=586
    D9ADM423442x0.2W120/240V120=76 | 240=41120V=8.6 | 240V=9Warm White=586
    D9ADH423442x0.2W120/240V120=76 | 240=41120V=8.6 | 240V=9Warm White=586

    IP68 WATERPROOF CONNECTORS

    Outdoor Bollard Lights with PMMA diffuser & SMD3030 LED. IP65 rating, die-cast aluminium body, BIS certification, 3000K & 6000K CCT. Available in powder coated colors of sanded black, light sanded grey and dark grey. Triac, PWM, 1-10V & Dali dimming available.

    Bollard lights are a type of architectural outdoor lighting fixture which gives off light from the top or the sides. It is used to illuminate steps, walkways or pathways. Available in various heights and designs. The uses of this light can be in playgrounds, roadways, malls, parks, parking spots and safety. Bollards are also applicable for security purpose and helps in managing traffic.
