Facade Wall Wash Lights
Facade Wall Wash Lights - B6R0656 | B6R1256 | B6R2456
Facade wall wash lights for prestigious lighting projects, exterior building design, modern building and commercial architecture. Wattage start from 6W to maximum of 48W with beam angle of 15, 20, 30 & 50 degree. Body material used is aluminium die-cast in powder coated colors of sanded grey, black and silver. Adjustable clamps and accessories are SS316 to protect the fixture from corrosion.
It also helps in highlighting the details and textures on a structure or wall and gives a modern look to the lighting space. Color temperatures available are 2000K, 3000K and 6000K. RGB and RGBW can also be provided along with DMX controls. Stunning designs with IP66 rating, Symmetric & Asymmetric lens are options in wall washer lights. Architects and lighting designers use wall washer fixtures for various high end outdoor lighting projects.
Some of the highlights are as follows:
Material Specifications B6R0656 | B6R1256 | B6R2456
- Housing:
- Extruded aluminium, Powder coated
- Lens:
- Optical lens, efficiency≥85%
- Light Window:
- Tempered glass T=4mm
- Cable gland:
- IP68 PG-9 PA66
- Gasket:
- Glass and housing are silicon sealed
- LED:
- OSRAM SMD3030
- Operating Temperature:
- -20⁰C-40C⁰
- Bracket:
- Hard Chrome plated stainless steel SUS 304# T=1.5mm
- Power Cable:
- 2XH05RN-F 2X1.0mm2 L=0.5m(low voltage) 2XH05RN-F 3X1.0mm2 L=0.5m(high voltage)
- CCT:
- 2000K/3000K/6000K
- Dimmable Support:
- Triac PWM 1-10V Dali
TECHNICAL DATA
| Model# | Light Source | LENS | Lens Degree | Length(MM) | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
|---|---|---|---|---|---|---|---|---|---|
| B6R0656 | 6x1.0W | B17 | 20⁰ | 265 | 24V DC | 120 | 240 | 24V=305 | 120V=100 | 240V=55 | 24V=7.5 | 120V=7.2 | 240V=7.3 | Cool White = 530 | Warm White = 512 | 02 |
| B6R1256 | 12x1.0W | B17 | 20⁰ | 510 | 24V DC | 120 | 240 | 24V=610 | 120V=130 | 240V=65 | 24V=14.5 | 120V=15 | 240V=15 | Cool White = 1080 | Warm White = 864 | 02 |
| B6R2456 | 24x1.0W | B17 | 20⁰ | 985 | 24V DC 120 | 240 | 24V=1220 | 120V=295 | 240V=163 | 24V=29 | 120V=35 | 240V=35 | Cool White = 2140 | Warm White = 1976 | 02 |
IP68 WATERPROOF CONNECTORS
Facade wall wash lights
Facade wall wash lights for prestigious lighting projects, exterior building design, modern building and commercial architecture. These are slim lights with different wattages, beam angles and color temperatures. Wattage starts from 6W to maximum of 48W. Beam angles offered are 15, 20, 30 and 50 degrees. Body material used is aluminium die-cast in powder coated colors of sanded grey, black and silver. Adjustable clamps and accessories are SS316 to protect the fixture from corrosion.
Color temperatures available are 2000K, 3000K and 6000K. RGB and RGBW can also be provided along with DMX controls. Architects and lighting designers use outdoor wall washer fixtures for high end commercial architecture. Product & Manufacturing process certifications include UL, CUL, SAA, TUV, CE, BIS, ISO-9001 & ISO -14005.
These fixtures can certainly light up facades of skyscrapers, modern building, airports and other city skylines. Wall washing illuminates a vertical surface with uniform brightness and draws attention to the outdoor wall. It can also accentuate an entrance, fireplace, or artwork.
There are a few things to keep in mind if you’re considering using outdoor wall washers. First, you’ll need to decide what type of fixture you want. There are two main types of wall washers: linear and grazing. Linear wall washers are designed to evenly illuminate a large area, while grazing fixtures create more of a “spotlight” effect. Wall washers evenly light up large areas and enhance the architecture.
