WALL WASHER
Wall Washer - B6KA1257 | B6KA2457
Wall washer are slim lights with different wattages, beam angles and color temperatures. These symmetrical IP66 wall washer comes with extruded aluminium housing & SUS 304# steel bracket. These fixtures use 1.5W OSRAM LED & comes with IK05 rating. Honeycomb louver is also an option for achieving anti-glare effect. Body material used is aluminium die-cast in powder coated colors of sanded grey, black and silver. Adjustable clamps and accessories are SS316 to protect the fixture from corrosion.
Color temperatures available are 2000K, 3000K and 6000K. RGB and RGBW can also be provided along with DMX controls. Stunning designs with IP66 rating, Symmetric & Asymmetric lens are options in wall washer lights. Architects and lighting designers use wall washer fixtures for various high end outdoor lighting projects. Applications of wall washers are infinite as there are different types of fixtures which suit different lighting needs. One can use these fixtures to highlight a wall structure or a wall design.
Some of the highlights are as follows:
Material Specifications: B6KA1257 | B6KA2457
- Housing:
- Extruded aluminium anodized finishing or Powder coated
- Lens:
- Optical lens, efficiency≥85%
- Light Window:
- Step Tempered glass T=4mm
- Cable gland:
- IP68 PG-9 PA66
- Gasket:
- Glass and housing are silicon sealed
- LED:
- OSRAM
- Operating Temperature:
- -20⁰C-40C⁰
- Bracket:
- Hard crome plated stainless Steel SUS 304#
- Power Cable:
- H07RN-F 2X1.0mm2 L=0.25m(low voltage)
- 2000K/3000K/6000K
- Dimmable Support:
- Triac PWM 1-10V Dali
TECHNICAL DATA
| Model# | Light Source | LENS | Lens Degree | Length(MM) | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
|---|---|---|---|---|---|---|---|---|---|
| B6KA1257 | 12x1.5W | B17 | 20⁰ | 493 | 24V DC | 24V=1000 | 24V=24 | Cool White = 1485 | Warm White = 1263 | 06 |
| B6KA2457 | 24x1.5W | B17 | 30⁰ | 973 | 24V DC | 24V=1985 | 24V=47 | Cool White =2900 | Warm White = 2470 | 06 |
IP68 WATERPROOF CONNECTORS
Symmetrical IP66 Wall Washer are slim lights with different wattages, beam angles and color temperatures. These symmetrical IP66 wall washer comes with extruded aluminium housing & SUS 304# steel bracket. These fixtures use 1.5W OSRAM LED & comes with IK05 rating. Honeycomb-louver is also an option for achieving anti-glare effect. Body material used is aluminium die-cast in powder coated colors of sanded grey, black and silver. Adjustable clamps and accessories are SS316 to protect the fixture from corrosion. Applications of wall washers are infinite as there are different types of fixtures which suit different lighting needs. One can use these fixtures to highlight a wall structure or any wall design. Symmetrical IP66 Wall Washer with SUS 304# steel bracket. 1.5W OSRAM LED, IK05 rating, optional honeycomb-louver, extruded aluminium housing.
Other outdoor products to choose from : Outdoor LED Lighting
The most popular reason to use an Symmetrical IP66 Wall Washer is to illuminate an architectural facade – typically lighting facades of skyscrapers & city skylines. These fixtures are available in RGB/RGBW/mono color and are often used to light up historic monument, government building and railway station.
If you’re looking for a way to add some extra light and interest to your home’s exterior, consider outdoor wall washers. These fixtures are designed to evenly illuminate large vertical surfaces, adding a touch of drama and helping to highlight the architecture of your home.
Symmetrical IP66 Wall Washer, IP65, IP66, IP67 & IP68 outdoor rated, mono or multi-color LED for lighting projects. Wattages start from 6W to a maximum of 120W. Standard beam angles offered are narrow to wide beams from 9, 12, 15, 20, 24, 40, 60. wall wash asymmetric beam angle of 10*30 and 15*32 can be provided as well.
Spacing between the wall washer and the surface helps to determine the level of brightness. For a focused, bright effect the fixture should be placed closer to the wall. Wall washers with high wattages can light up buildings upto 50 floors high. The purpose of wall washers is to illuminate vertical surfaces and enhance the architecture.
