Wall Mounted Spot Light



LED Focus Lights R3PFM0171
Wall mounted spot light for high-end lighting projects, warm white light effect, modern farmhouse lighting and spot lights for resorts. These fixtures can be wall mounted to give a beautiful wall wash effect. These are sturdy and high quality fixtures highly recommended by lighting designers for various lighting projects.
The fixture can be tilted to adjust the light direction and get the desired effect. Various housing colors can be provided with cool white CCT, 100⁰ beam & 20W NICHIA LED to suit the lighting space and create fabulous lighting effects. Wall mounted spot light for landscape and outdoor projects at competitive prices and quality certifications.
Some of the highlights are as follows:
Material Specifications R3PFM0171
- Front cover & Housing:
- 12# Die-casting dark grey powder coated aluminium
- Lens Window:
- Tempered glass. T=4mm
- Reflector:
- Optical Reflector efficiency ≥90%
- LED:
- NICHIA COB LED
- Power Cable:
- H05RN-F 2X1.0mm2 L=2.0m(low voltage) H05RN-F 3X1.0mm2 L=2.0m(high voltage)
- CCT:
- 3000K/6000K
TECHNICAL DATA
Model# | Light Source | LENS | Lens Degree | Input Voltage | Operating Current(MA) | Consumption (W) | Lumance (LM) | IK |
---|---|---|---|---|---|---|---|---|
R3PFM0171 | 1x20W | R12 | 100⁰ | 24V DC | 120 | 240 | 24V=960 | 120V=205 | 240V=105 | 24V=23 | 120V=24 | 240V=24.4 | Cool White=1885 | Warm White=1678 | 08 |


IP68 WATERPROOF CONNECTORS




Wall mounted spot light
Wall mounted spot light for high-end lighting projects, warm white light effect, modern farmhouse lighting and spot lights for resorts. These fixtures can also give a beautiful wall wash effect. These are sturdy and high quality fixtures highly recommended by lighting designers for various lighting projects.
Spot lights for resorts can be tilted to adjust the light direction and get the desired effect. Various housing colors can be provided with cool white CCT, 100⁰ beam & 20W NICHIA LED to suit the lighting space and create fabulous lighting effects. Wall mounted spot light for landscape and outdoor projects at competitive prices and quality certifications.
Applications for spotlights can be in building facades, stage lighting, landscape lighting or high-end lighting projects. Each fixture caters to different outdoor lighting applications. Small sized fixture with multiple beam angles & spikes for highlighting shrubs. These high-quality focus spot light fixtures come with housing color options and weatherproof body at best prices.
They also give a nice warm white light effect and the applications include modern farmhouse lighting. These high quality LED fixtures come in 50+ designs to suit various architectural lighting projects. Spot lights come with multiple dimming support and DMX controls help to achieve different light patterns. Also available in RGB/RGBW with low-high wattage options and weatherproof body. These lights also feature a strong and bright LED light that can span up to 120 degrees, making them ideal for illuminating any outdoor space.
